E
@shbatm
@shbatm said in [MMM-RTSPStream] - Video Streaming from Live Feeds & Security Cameras:
Looking at the logs it looks like it’s trying to launch everything correctly. Just to confirm:
The stream works correctly in VLC using the URL you have above.
Since you’re using OMXPlayer – you are testing on the mirror with the RPi connected (not with VNC/Remote Desktop, etc). You won’t see playback from OMXPlayer on anything but the monitor connected to the RPi.
Yes, it does work in VLC.
I control RPi via SSH & VNC, but it is connected via HDMI to monitor and I don’t see any output on the actual screen neither via VNC, nor actual screen.
Testing:
By making tests I encounter an error:
pi@raspberrypi:~ $ sudo reboot
login as: pi
pi@192.168.2.111's password:
Linux raspberrypi 4.14.50-v7+ #1122 SMP Tue Jun 19 12:26:26 BST 2018 armv7l
The programs included with the Debian GNU/Linux system are free software;
the exact distribution terms for each program are described in the
individual files in /usr/share/doc/*/copyright.
Debian GNU/Linux comes with ABSOLUTELY NO WARRANTY, to the extent
permitted by applicable law.
Last login: Mon Sep 24 01:55:35 2018
SSH is enabled and the default password for the 'pi' user has not been changed.
This is a security risk - please login as the 'pi' user and type 'passwd' to set a new password.
pi@raspberrypi:~ $ pm2 stop mm
[PM2] Applying action stopProcessId on app [mm](ids: 0)
[PM2] [mm](0) ✓
┌──────────┬────┬──────┬─────┬─────────┬─────────┬────────┬─────┬────────┬──────┬──────────┐
│ App name │ id │ mode │ pid │ status │ restart │ uptime │ cpu │ mem │ user │ watching │
├──────────┼────┼──────┼─────┼─────────┼─────────┼────────┼─────┼────────┼──────┼──────────┤
│ mm │ 0 │ fork │ 0 │ stopped │ 0 │ 0 │ 0% │ 0 B │ pi │ disabled │
└──────────┴────┴──────┴─────┴─────────┴─────────┴────────┴─────┴────────┴──────┴──────────┘
Use `pm2 show ` to get more details about an app
pi@raspberrypi:~ $ omxplayer --avdict rtsp_transport:tcp --win 800, 421, 1120, 661 --live --video_queue 4 --fps 30 rtsp://192.168.2.237:554/user=USER&password=PASS&channel=1&stream=0.sdp
[1] 1084
[2] 1085
[3] 1086
pi@raspberrypi:~ $ File "421," not found.
pi@raspberrypi:~ $
Did not work
Also did not work, this time another file is not being found
omxplayer --avdict 421, 1120, 661 --live --video_queue 4 --fps 30 rtsp://192.168.2.237:554/user=USER&password=PASS&channel=1&stream=0
[7] 1213
[8] 1214
[9] 1215
[4] Exit 1 omxplayer --avdict 421, 1120, 661 --live --video_queue 4 --fps 30 rtsp://192.168.2.237:554/user=USERNAME
[5] Done password=PASSWORD
[6] Done channel=1
pi@raspberrypi:~ $ File "1120," not found.
5., Did not work
pi@raspberrypi:~ $ File "421," not found.
